* Pictures are placed for illustration purpose only. Appearance of real component may differ.
Aluminum electrolythic capacitor for aplication in DC and pulsed current circuits.
| Type | Rated voltage,V | Rated capacitance,uF | Tolerance,% | Dimensions,mm | ||
| D (Н) | L | B | ||||
| К50-3А (К50-3Б) | 6 | (10-5000) | +50÷ -20 | 4,5-32 | 19-72 | — |
| 12 | 2-500 (2-2000) | 6-32 | 22-72 | — | ||
| (4,5-32) | (14-62) | |||||
| 25 | 2-1000 (2-2000) | 6-40 | 29-106 | — | ||
| (4,5-32) | (19-72) | |||||
| 50 | 1-200 (1-2000) | 6-32 | 29-62 | — | ||
| (4,5-32) | (19-86) | |||||
| 100 | 1-100 (1-200) | 6-32 | 29-62 | — | ||
| (22-52) | ||||||
| 160 | 2-50 (2-200) | 12-25 | 30-56 | — | ||
| (8,5-32) | (36—62) | |||||
| 250 | (20, 50) | (25,25) | (40, 56) | — | ||
| 300 | 5-50 (5-50) | 17-32 | 42-106 | — | ||
| (17-32) | (30-52) | |||||
| 350 | 2-20 (2-20) | 17-32 | 42-62 | — | ||
| (12-25) | (30-56) | |||||
| 450 | 2-20 (2-20) | 17-32 | 42-86 | — | ||
| (17-32) | (30-52) | |||||
You can order K50-3B 20mkF 50V from us
